| 性能特点 |
在薄板横剪线的基础上，增加纵剪功能，工件经纵剪后再定长撗剪；如果不需纵剪，抬起纵剪上刀轴，可作为
普通横剪线使用。特别适合于汽车、电气、制罐等行业。
由上料小车、开卷机、引头装置、牵引夹送及校平、缓冲活套、对中装置、定长送料-纵剪主机、剪板机、输 送出料、落料装置等组成。
可另外选配活套后面的二次校平及主机主机后面的废边卷取装置。 | |
| Features: |
Add slitting function on the basic of cut-to-length line for thin plate, fixed length crossing cut after slitting; lift the slit blade shaft if no need slitting, it can use as a cross-cutting line. It is suitable for industries such as car, electronic, jar-making etc,
It consists of feeding car, uncoiler, traction device, strip feeding and leveling, buffer loop, centering device, cut-to-length feeding, slitting machine, shearing machine, transport output, discharging device etc.
Can according to customer’ s request to choose optional second level machine and wasted-recoil device. | |
|
 |
|
 |
|
| 主要技术参数 Specifications |
| 项目 Name |
单位 Unit |
可选择范围 Optional range |
| 加工板厚 Plate thickness |
mm |
0.3-1.5 0.4-2.0 0.5-3.0 |
| 标准板宽 Standard width |
mm |
1300 1600 |
| 开卷机承重 Uncoiled weight |
T |
6-15 |
| 纵剪宽度精度 Slitting width precision |
mm |
±0.05-0.1 |
| 最多分条数 Max, slitting number |
pcs |
5-20 |
| 定尺精度 Cutting length precision |
mm/2m |
±0.5-1.5 |
| 定长范围 Cutting length range |
mm |
500-4000 |
| 机组最高线速度 Highest line speed |
m/min |
20-60 |
| 机组总功率 Total power |
Kw |
60-150 | | |
|
| 本表所列参数，不作为产品检验依据，仅供产品选型参考。如出现与产品实际数据有不一致处，应遵照说明书或双方的技术协议约定。 |
| The data in file not as inspection evidence, just reference for model chosen. If any difference with actual data, please refer to manual or technical agreement by both parties. | |
